Solution Example 1 - System Diagram

Small Conference Room (10-20 People) Conference System + Professional Sound Reinforcement System , Area: 100㎡

Product List

● The system adopts wireless transmission, no need for cables, with wide signal coverage, high fidelity, high signal-to-noise ratio, low latency, etc., which ensures the real playback of the sound signal, so that the participants can feel the real existence of the sound source, achieving high-fidelity sound reinforcement needs.

● The conference system is composed of the wireless conference host DW9866 and conference units, as well as professinal sound system. When the participant speaks to the chairman conference unit DW60 or the delegate conference unit DW61, the audio is processed through the mixing console DMX08 and sent to the power amplifier MX1500II, and then amplified through the power amplifier and further sent to the speaker.

● Eight 20W ceiling speakers DSP915 are evenly installed on the ceiling of the conference room for short-distance sound reinforcement, with appropriate loudness, good diffusion and uniform sound field.

● Applicable to 100㎡ small conference rooms, small auditoriums and other places with requirements for sound reinforcement.

Solution Example 2 - System Diagram

Medium-sized Conference Room (20-60 People) Conference System + Professional Sound Reinforcement System, Area: 200㎡

Product List

● The whole system is mainly composed of the DW9866 conference system and professional sound system. Among them, the professional sound system is mainly composed of speakers, power amplifiers, mixing consoles, microphones, sound source equipment and other equipment, which can meet the needs of simple meetings, speeches, seminars, etc.

● The professional audio processing equipment (DMX12, D6573 and D6575) make the live speech clear, without distortion or sound feedback howling, etc.

● The conference system is composed of the wireless conference host DW9866 and conference units, as well as professinal sound system. When the participant speaks to the chairman conference unit DW63 or the delegate conference unit DW64, the audio is processed through the mixing console DMX12 and sent to the power amplifier MX1500II, and then amplified through the power amplifier and further sent to the speaker D6563 to realize local sound reinforcement. The system plan is used for demonstration, and 2 speakers D6563 can make the conference with sufficient on-site sound pressure margin, uniform sound field and accurate sound image positioning, enabling the simplest and most economical audio conference system.

● Suitable for 200㎡ large and medium-sized conference rooms, lecture halls, auditoriums and other places with requirements for sound reinforcement.
